Alarming Cable Lock

Alarming Cable Lock - Product Manual

I. Product Overview

Designed specifically for anti-theft protection, this product integrates **three-fold electronic alarm + physical cable traction anti-theft** dual safeguards. It is suitable for scenarios such as merchandise display, luggage security, and equipment anti-theft, featuring easy operation and comprehensive protection.

II. Core Functions

(1) Three-Fold Alarm Protection

1. Cable Cutting Alarm: Triggers a high-decibel alarm immediately when the steel cable is cut by external force;

2. Main Unit Prying Alarm: Activates the alarm instantly if the main unit is pried open violently, causing the bottom contact to detach;

3. Steel Pin Pulling Alarm: The system quickly emits an alarm when the locked steel pin is illegally pulled out.

(2) Additional Functions

1. Low Battery Reminder: Emits a "beep" every 30 seconds when the battery is nearly exhausted;

2. Automatic Alarm Deactivation: The alarm stops automatically if no operation is performed within 180 seconds after triggering;

3. Rechargeable Battery: Supports repeated charging; retains physical anti-theft function when power is off.

III. Key Specifications

| Parameter Name               | Specific Specifications                  |

|------------------------------|-------------------------------------------|

| Charging Interface           | Micro USB                                 |

| Charging Voltage/Current     | 5V 1A                                     |

| Arm Status Prompt            | "Beep" sound when the contact is pressed  |

| Low Battery Reminder Frequency | 1 "beep" every 30 seconds                |

| Automatic Alarm Off Time     | 180 seconds after triggering (no operation) |

| Function Retention When Power Off | Only physical anti-theft (steel cable traction) |

IV. Usage Instructions

(1) Main Unit Installation & Operation

1. Arming Steps

- Step 1: Tear off the protective film of the double-sided tape on the bottom of the main unit, and stick it on a flat, dry, and oil-free surface;

- Step 2: Press the main unit to ensure the bottom contact is fully pressed. A "beep" sound indicates successful arming.

2. Alarm Deactivation

- Manual Deactivation: Aim the remote control at the main unit and press the "OFF" button to stop the alarm immediately;

- Automatic Deactivation: The alarm turns off automatically if no operation is performed within 180 seconds after triggering.

3. Charging Operation

- Low Battery Identification: The device emits a "beep" every 30 seconds, indicating the need for charging;

- Charging Connection: Use a 5V 1A Micro USB power adapter to connect to the charging port;

- Charging Status: The arming function can be used normally during charging. The low battery reminder disappears when fully charged;

- Power Off Note: When the battery is completely exhausted, the electronic alarm function becomes invalid, and only the physical anti-theft function is retained.

(2) Steel Cable Anti-Theft Binding

1. Unlocking Operation

- Take out the matching magnetic key, attach it to the lock buckle for adsorption and unlocking, then remove the steel pin;

2. Binding Steps

- Step 1: Pass the steel cable through the item to be protected (such as merchandise, luggage, equipment, etc.);

- Step 2: Reinsert the steel pin into the lock buckle. A "click" sound indicates successful locking;

- Step 3: Put back the magnetic key to complete the anti-theft binding.

V. Notes

1. Ensure the bottom contact of the main unit is fully pressed during installation; otherwise, arming will fail;

2. Only use a power adapter of the specified specification (5V 1A) for charging to avoid damaging the device due to high voltage;

3. Keep the magnetic key properly. Loss of the key will prevent unlocking the steel pin, affecting product reuse;

4. The sticking surface must be clean and dry; otherwise, the main unit may fall off, affecting the protection effect;

5. Avoid contact with water, oil, and other corrosive substances to extend the service life of the device.
